Designed in the shadow of the stunning Scottish mountains, the Deviate Claymore has been made to be the ultimate enduro mountain bike. Named after the devastating two-handed sword used by medieval warriors the big travel Claymore is ready to take on any challenge.
The Deviate Claymore frame can be purchased as a all-out speed 29" wheel or agile MX wheel (29" front / 27.5" rear) set-up - this listing is for the MX version. Travel wise, Deviate recommend you fit 170mm or 180mm forks, the rear-end has 165mm travel to play with. Big numbers for big, technical features.
Deviate frames are made to exceptionally high quality and are as such covered by a lifetime warranty. Also, as a Deviate owner your benefit from lifetime frame bearing replacement.
Key Features -
Full Carbon frame
High-pivot suspension
170/180mm front (recommended)
165mm rear travel
MX wheel ready set-up
Threaded 73mm BB shell
ZS44/28.6 upper and ZS56/40 lower headset sizing
Internal dropper routing 34.9”
Fully Sealed Bearings
Bearing Grease Ports
18T Chain Idler
Downtube Protector
Contact us at support@biketart.com if you wish to discuss components or to arrange your own custom built dream enduro bike
SIZING -
M: 5'6 - 5'11
L: 5'10 - 6'2
XL: 6'1 - 6'5
Pinkbike’s ‘Enduro Race Bike of Choice 2022’ - “This is a bike I genuinely want to race - I thought that from the first ride. I got on and was like “I want to take this to an Enduro race.” - Alicia Leggett, Pinkbike
Specifications::Claymore MX Frame
Discipline: Enduro/Race
Material: Carbon
Front Travel: 170mm/180mm
Rear Travel: 165mm
Wheel Size: MX
Warranty: Lifetime (frame)
Rear Wheel: 27.5”, Boost: 148mm x 12mm
Fork Compatibility: 29” 170 or 180mm with 44/42mm offset | Fork crown interference with downtube MUST be checked before fitting forks
Shock: Fox Float X2
Bottom Bracket: 73mm BSA Threaded
Headset: ZS44/28.6 upper and a ZS56/40 lower headset cup
Cranks: Minimum Q-factor of 168mm
Chainline: 52mm or 55mm options available
Chain length: 126 links (widely available, no need to join chains)
